| TECHNICAL SPECIFICATIONS | |
|---|
| Mono Inputs | |
| Mic Inputs (XENYX Mic preamp) | 4 |
| Type | XLR connector, balanced, discrete input circuitry |
| Microphone E.I.N. (20 Hz - 20 kHz) | |
| @ 0 Ω source resistance | -134 dB / -136 dB A-weighted |
| @ 50 Ω source resistance | -132 dB / -135 dB A-weighted |
| @ 150 Ω source resistance | -131 dB / -133 dB A-weighted |
| Frequency response (-1 dB) | <10 Hz - 150 kHz (-1 dB) |
| Frequency response (-3 dB) | <10 Hz - 200 kHz (-3 dB) |
| Gain range | +10 dB to +60 dB |
| Max. input level | +12 dBu @ +10 dB gain |
| Impedance | 2 kΩ balanced |
| Signal-to-noise ratio | 108 dB / 110 dB A-weighted (0 dBu input @ +22 dB gain) |
| Distortion (THD+N) | 0.005 / %0.004 A-weighted |
| Phantom power | Switchable, +48 V |
| Line Input | |
| Type | 1/4” TRS connector, balanced |
| Impedance | 20 kΩ balanced, 10 kΩ unbalanced |
| Gain range | -10 dB to +40 dB |
| Max. input level | 30 dBu |
| Frequency Response (Mic In Main Out) | |
| <10 Hz - 160 kHz | ±3 dB |
| Stereo Inputs | |
| Type | 2 x 1/4” TRS connector, balanced |
| Impedance | 20 kΩ balanced, 10 kΩ unbalanced |
| Gain range | -20 dB to +20 dB |
| Max. input level | +22 dBu |
| 2-Track Input | |
| Type | RCA connector |
| Impedance | 10 kΩ |
| Max. input level | +22 dBu |
| Equalizer 3-Band | |
| Low | 80 Hz / ±15 dB |
| Mid | 2.5 kHz / ±15 dB |
| High | 12 kHz / ±15 dB |
| AUX Sends | |
| Type | 2 x 1/4” TRS connector, balanced |
| Impedance | 120 Ω |
| Max. output level | +22 dBu |
| AUX Returns | |
| Type | 2 x 1/4” TRS connector, balanced |
| Impedance | 20 kΩ balanced, 10 kΩ unbalanced |
| Max. input level | +22 dBu |
| Main Outputs | |
| Type | XLR connector, balanced |
| Impedance | 240 Ω balanced, 120 Ω unbalanced |
| Max. output level | +28 dBu |
| Control Room Output | |
| Type | 1/4” TRS connector, balanced |
| Impedance | 120 Ω |
| Max. output level | +22 dBu |
| Phones Output | |
| Type | 1/4” TRS connector, unbalanced |
| Impedance | 25 Ω |
| Max. output level | +21 dBu / 150 Ω (+25 dBm) |
| 2-Track Out | |
| Type | RCA connector |
| Impedance | 1 kΩ |
| Max. output level< | +22 dBu |
| DSP | |
| Type | Klark Teknik |
| Converter | 24-bit Sigma-Delta
64/128-timesoversampling |
| Sample rate | 40 kHz |
| Wireless Input | |
| USB dongle | Accepts signals from 2 independent Behringer ULM microphones |
| Main Mix System Data (Noise) | |
| Main mix @ -∞, channel fader @ -∞ | -105 dB / -108 dB A-weighted |
| Main mix @ 0 dB, channel fader @ -∞ | -95 dB / -97 dB A-weighted |
| Main mix @ 0 dB, channel fader @ 0 dB | -83 dB / -85 dB A-weighted |
| Power Supply | |
| Voltage supply | 100 - 240 V~, 50/60 Hz |
| Power consumption | 40 W |
| Fuse (100 - 240 V~, 50/60 Hz) | T 1.6 A H 250 V |
| Main connector | Standard IEC receptacle |
| USB | |
| Connector | Type B |
| Audio | Stereo input/output |
| Converter | 16-bit |
| Sample rate | Sample rate |
| Dimensions and Weight | |
| Dimensions (W x D x H) | 10.4 x 13 x 3.5”
265 x 330 x 90 mm |
| Weight | 6.3 lbs / 2.9 kg |
|
