Studiomaster DigiLive 16P-600 is a compact and powerful digital mixer. The device has 16 inputs and 16 internal buses, including 12 digital gain mic input channels and 2 stereo inputs. It also offers 4 configurable smart outputs. The mixer's ultra-compact design, 7-inch high-resolution touchscreen, and advanced hybrid user interface take the user experience to the next level.
Features:
- Inputs: 12 mic inputs (8 XLR, 4 Combo XLR) and 2 stereo inputs.
- Outputs: 2 main outputs (balanced XLR left/right), 4 assignable smart outputs (balanced XLR), and 4 sets of 4-pole speaker outputs.
- Internal Buses: 16 internal buses.
- Screen: 7-inch high-resolution touchscreen.
- Operating System: Android-based system.
- Network Connection: Network connection via included Wi-Fi module.
- Remote Control: Remote control via 'Digilive Blackbox' app on iPad iOS.
- Sampling Frequency: 48 KHz.
- AD/DA Conversion: 192 KHz, 24-bit.
- DSP: 40-bit floating point, SHARC processor.
- Effects: Up to 8 assignable effect modules.
- Amplifier Power: 4 x 150 watts (RMS).
- AES/EBU: XLR output.
- S/PDIF: Input/Output (RCA Phono).
- USB Interface: 2 ports for playback/recording, scene/setting storage, and system updates.
- Power Supply: 100-120V/200-240V ~ 50/60Hz IEC power supply.
DigiLive 16P-600 is equipped with a built-in 600-watt digital power amplifier and has an ultra-compact unit size. It provides ease of use with its 7-inch high-resolution touchscreen and advanced hybrid user interface.
This mixer is an ideal solution for live performances and studio recordings. With its compact design and powerful features, it is an excellent choice for professional sound engineers and musicians.
