Tascam MZ-223 3-Zone Mixer, For installation 19", 2U

Barcode: 2242005424230
Brand: Tascam
Category: 19" Rack Mount Mixer
26.562 TL
FREE CARGO

2.745 TL in installments starting from ..

price for Piece

Fast Shipping

Secure shopping

Returns and Exchanges

Tascam MZ-223 3-Zone Mixer, For installation

Audio inputs
Microphone inputs 1–2	Balanced: XLR-3-31 (1: GND, 2: HOT, 3: COLD) Unbalanced: 6.3-mm TRS jacks (Tip: HOT, Ring: COLD, Sleeve: GND)
Input impedance	33 kΩ
Nominal input level	–65 dBu (VOLUME knob at MAX) Unbalanced: –30 dBu (VOLUME knob at MIN)
Line inputs (unbalanced)	RCA pin jacks
Nominal input level	–10 dBV
Maximum input level	10 dBV
Input impedance	22 kΩ

Audio outputs
Main outputs (unbalanced)	RCA pin jacks
Nominal output level	–10 dBV
Maximum output level	6 dBV
Output impedance	200 Ω
Main outputs (balanced)	XLR-3-32 (1: GND, 2: HOT, 3: COLD)
Nominal output level	4 dBu
Maximum output level	24 dBu
Output impedance	200 Ω
Monitor outputs	RCA pin jacks
Nominal output level	–16 dBV
Maximum output level	0 dBV
Output impedance	200 Ω
Headphones output	6.3-mm stereo jack
Maximum output power	50 mW + 50 mW (into 32 Ω load)

Audio performance
Frequency response	20 Hz – 20 kHz
Distortion	≤0.03%
Crosstalk	65 dB

Power supply and other specifications
Power supply	Dedicated AC adapter (PS-M1524)
Input voltage	AC 100–240 V, 50/60 Hz
Output voltage	DC 15 V
Output current	2.4 A
Power consumption	35 W
Overall dimensions (width × height × depth)	482 mm × 88 mm × 93 mm
Weight	2.5 kg
Permissible operating temperature	5–35 °C
