| Chassis Size | 203.2 mm (8") |
| Color | Black |
| Input Connections | Parallel Neutrik® NL4 |
| Speaker Type | Full-range, Mid-High, Two-Way, Wedges |
| Frequency Response (-3 dB) | 60 - 20000 Hz |
| Frequency Response (-10 dB) | 48 - 20000 Hz |
| Internal Crossover | Yes |
| Recommended High-Pass Frequency | 40 Hz |
| Sensitivity 1 W/1 m | 94 dB |
| Max. SPL/1m (calc) | 123 dB |
| Coverage (Nominal -6 dB) H | 90 ° Rotatable |
| Coverage (Nominal -6 dB) V | 50 ° Rotatable |
| Rotatable Horn | Yes |
| System Power Handling (Continuous/Program/Peak) | 200//800 Watts |
| LF Transducer | 8-inch EV8L |
| HF Transducer | 1.25-inch DH2005 |
| Crossover Frequency | 1700 Hz |
| Nominal Impedance (Passive) | 8 Ω |
| Minimum Impedance | 6 Ω |
| Enclosure Material | High Impact Polystyrene |
| Flying | No |
| Outdoor | No |
| Grill | Polyester Powder Coated, 18GA Galvanized Steel |
| Height | 457 mm (17.99") |
| Width | 282 mm (11.1") |
| Depth | 264 mm (10.39") |
| Weight Net | 8.4 kg (18.52 lbs) |
