| Power source | 100 - 240 V AC, 50 / 60 Hz |
|---|
| Power / current consumption | 48 W (EN62368-1), 171 W (rated output) |
|---|
| Frequency response | 50 Hz - 20 kHz |
|---|
| Rated output | 120 W |
|---|
| Speaker output | Speaker: low impedance: 4-16 Ω, high impedance: 100 V, direct, zone 1, zone 2. |
|---|
| Control input | 4 channels, no-voltage make contact input, open voltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (3.81 mm, 4 pins) |
|---|
| Control output | Power remote, emergency, zone control: withstand voltage 30 VDC, control current 25 mA or less, removable terminal block |
|---|
| Controls | 7x volume for inputs, bass, treble, master volume, zone 1 & 2 switch, power |
|---|
| Operating temperature | - 10 °C to + 40 °C (14 °F to 104 °F) |
|---|
| Finish | ABS resin, black |
|---|
| Dimensions | 420 x 96.1 x 313.1 mm (W x H x D) |
|---|
| Distortion | < 1 % (at 1 kHz, rated power) |
|---|
| Amplifier | Class D |
|---|
| S/N ratio | 88 dB(A) (A-weighted) |
|---|
| Connectable microphones | 6 |
|---|
| Inputs | Input 1+2: -60/-20 dBV, 600 Ω, balanced, phantom power switchable; Inputs 3+4: -60 dBV, 600 Ω, balanced, phantom power switchable; all with removable terminal block; Inputs 5+6: -60 dBV, 600 Ω, balanced, removable terminal block / -20 dBV, 10 kΩ, unbalanced, RCA jacks, selectanble; Input 7: -20 dBV, 10 kΩ, unbalanced, 2 RCA jacks. Power amplifier input 0 dBV, 600 Ω, unbalanced, RCA jack |
|---|
| Outputs | Recording, line out 1+2: 0 dBV, 600 Ω, unbalanced, RCA jack. Line out can be interlocked with zones. |
|---|
