Electrical
• Standard 230V, 50/60Hz power supply (others available on request)
• Lamp-holder type GY 9.5
• 2m power supply cable (plug available on request)
• Strain relief cable clamp entry into light housing
Safety
• Safety mesh
• Filter-frame locking system
• Compliance to CE EN 60598-2-17 standards
Optical
• Spherical reflector in 99.99% polished and treated aluminium:
70mm diameter
• 110mm diameter borosilicate lens mounted onto extended holders to allow ventilation
Mechanical
• Extruded aluminium and steel housing
• Black Epoxy Resin paint
• Labyrinth ventilation to avoid light spillage
Operational
• Access for lamp maintenance via removable top cover
• Yoke with 10mm diameter hole, adjustable height, reversible and
sliding into extruded rails to balance accessories and for use in any position
• Heat insulated knobs and handles
• Focus adjustment by an endless screw mechanism operated by rear knob
Size in mm
Light Output: Spot 5°
Light Output: Flood 56°
