| | Electrical |
| • | Standard 230V, 50/60Hz power supply (others available on request) |
| • | Lamp-holder type GY 9.5 |
| • | 2m power supply cable (plug available on request) |
| • | Strain relief cable clamp entry into light housing |
| | Safety |
| • | Safety mesh |
| • | Filter-frame locking system |
| • | Compliance to CE EN 60598-2-17 standards |
| | Optical |
| • | Spherical reflector in 99.99% polished and treated aluminium:
70mm diameter |
| • | 110mm diameter borosilicate lens mounted onto extended holders to allow ventilation |
| | Mechanical |
| • | Extruded aluminium and steel housing |
| • | Black Epoxy Resin paint |
| • | Labyrinth ventilation to avoid light spillage |
| | Operational |
| • | Access for lamp maintenance via removable top cover |
| • | Yoke with 10mm diameter hole, adjustable height, reversible and
sliding into extruded rails to balance accessories and for use in any position |
| • | Heat insulated knobs and handles |
| • | Focus adjustment by an endless screw mechanism operated by rear knob |
