| Model | L5 115 F |
| Max SPL | 130 dB half space |
| Max SPL peak | 139 dB half space |
| Power-handling nominal (RMS) | 600 Watt |
| Power-handling, peak | 2400 Watt |
| Power-handling, program | 1200 Watt |
| Frequency response +/- 3 dB | 60 Hz - 18 kHz |
| Frequency response -10 dB | 55 Hz - 20 kHz |
| Nominal impedance | 8 Ohm |
| Sensitivity 1W | 106 dB |
| Connections | 2 x Speakon NL 4 |
| Low/ Mid Speaker | 15" with 3" voice coil |
| HF Driver | 1" with 1,75" voice coil |
| Horn characteristics | 60°- 90° (asy) x 55° CD horn, rotatable |
| Equalizer | EQ switch Flat / Contour |
| Crossover frequency | 1,7 kHz, 12dB/Oktave |
| Pole mount | Duo Tilt 3/7 |
| Rigging points | 3 x M8 |
| Handles | 2 integrated |
| Optional accessories | Protective cover |
| Enclosure | Hybrid (birch multiplex / MDF) |
| Grille | 2 mm metal grille backed with black acoustic foam |
| Finish | Acrylic enamel, black |
| Dimensions (WxHxD) | 44,9 x 70,8 x 45 cm |
| Weight | 30,1 kg / 66,4 lbs |
