Teknik Özellikleri
1.000 watt işleyebilen bu son derece verimli 15 / 1 tam boyutlu orta / yüksek birim, sınıfının en yüksek referans hoparlördür. L5 FA 112 de olduğu gibi, öne genişleyen ve mesafe ile daha fazla yönlendirilen optimize edilmiş kapsama deseniyle asimetrik bir boynuz bulunur ve böylece daha geniş menzil elde edilir.
| Model | L5 115 FA |
| Max SPL | 129 dB half space |
| Max SPL calculated | 139 dB half space |
| Max SPL peak | 139 dB half space |
| Cut-off Frequency active | 1,65 kHz, 24 dB/Oktave |
| Power Rating | 1000 Watt |
| Frequency response +/- 3 dB | 57 Hz - 18 kHz |
| Frequency response -10 dB | 48 Hz - 20 kHz |
| Sensitivity HF, 1W/1m | 110 dB full space / 116 dB half space |
| Sensitivity LF, 1W/1m | 100 dB full space / 106 dB half space |
| Low/Midrange amplifier | 650 Watt @ 4 Ohm |
| HF Amplifier | 350 Watt @ 4 Ohm |
| Active protectiion circuits | Undervoltage-Protection, Thermoprotection, Short-Circuit Protection, Overcurrent-Protection |
| Input Sensitivity | +4dBu @ Gain Centerclick / L5 System Level |
| Protection | Subsonic 24dB/Oktave, Peak Limiter |
| Connections | 2 x XLR- Combi IN, 2 x XLR-Thru, 1 x XLR-Mix Out |
| Low/ Mid Speaker | 15" with 3" voice coil (4 Ohm) |
| HF Driver | 1" with 1,75" voice coil (16 Ohm) |
| Horn characteristics | 60°- 90°(asy) x 55° CD Horn, rotatable |
| Equalizer | EQ switch Small Venue / High Power |
| Subsonic filter | yes |
| Peak limiter | yes |
| Amplifier | Class D - Biamped |
| Sensitivity switch | yes - Line/Mic Input A |
| Pole mount | Duo Tilt 3/7 |
| Rigging points | 3 x M8 |
| Handles | 2 integrated |
| Optional accessories | Protective cover |
| Enclosure | Hybrid (birch multiplex / MDF) |
| Grille | 2 mm metal grille backed with black acoustic foam |
| Finish | Acrylic enamel, black |
| Dimensions (WxHxD) | 44,9 x 70,8 x 45 cm |
| Weight | 30,7 kg / 67,7 lbs |
