| Model | L Sub 2000 A |
| Max SPL calculated | 135 dB half space |
| Max SPL peak | 133 dB half space |
| Cut-off Frequency active | 100Hz / 120Hz variable with 24 dB/Oktave |
| Max SPL | 132 dB half space |
| Power Rating | 1200 Watt |
| Frequency response +/- 3 dB | 49 Hz - X-Over |
| Frequency response -10 dB | 39 Hz - X-Over |
| subwoofer amplifier | 1200 Watt @ 4 Ohm |
| Active protectiion circuits | Undervoltage-Protection, Thermoprotection, Short-Circuit Protection, Overcurrent-Protection |
| Input Sensitivity | +4dBu @ Gain Centerclick |
| Protection | Subsonic 24dB/Oktave, Peak Limiter |
| Connections | 2 x XLR- Combi IN, 2 x XLR-Thru, 2 x XLR-Mid/High Out |
| LF Speaker | 2 x 12" (8 Ohm) with 2,5" voice coil featuring Advanced-Cooling-Technologie |
| Subsonic filter | yes |
| Peak limiter | yes |
| Amplifier | Class D |
| Pole mount | M 20 |
| Handles | 4 integrated |
| Optional accessories | Protective Cover, 100mm Blue Wheels, Tilt Unit |
| Enclosure | Birch multiplex 15/18 mm, 9/13 ply |
| Grille | 2mm metal grille |
| Finish | Acrylic enamel, black |
| Dimensions (WxHxD) | 50,6 x 80,6 x 61 cm |
| Weight | 47,5 kg / 104,7 lbs |
