Neumann KH 120 A W 5+1" Aktif Monitor

Stokta yok veya sipariş üzerine tedarik edilir. Lütfen iletişime geçiniz: 0 (533) 592 49 10
  • Yüksek verime sahip kompakt çift amplifikatörlü stüdyo monitörü

  • Olağanüstü bas derinliği ve 52 ila 21 k Hz arasında geçici yanıt

  • Yakın alan uygulamaları için optimize edilmiş hassas dağılım

  • KH 750 DSP ve iPad® uygulamasına sahip bir stereo sistem olarak, kontrol edilebilir ve odaya göre hizalanabilir



Free field frequency response ±6 dB46 Hz … 24 kHz
Free field frequency response ±3 dB52 Hz … 21 kHz
Free field frequency linearity deviation between 100 Hz and 10 kHz± 1.0 dB
Reproduction accuracy between 100 Hz and 10 kHz: 100%, 80%, 50% of loudspeakers produced±0.97; ±0.40; ±0.23 dB
Self-generated noise at 10 cm (with input gain set to 100 dB SPL for 0 dBu)<20 dB(A) SPL
Sine wave output with a THD < 0.5 % at 1 m in half space95 dB SPL (>120 Hz)
Max. SPL calc. in half space at 3% THD at 1m (averaged between 100 Hz and 6 kHz)111.1 dB SPL
Max. SPL in full space at 3% THD at 1m (averaged between 100 Hz and 6 kHz)105.1 dB SPL
Bass capability: Max. SPL in half space at 3% THD at 1m (averaged between 50 Hz and 100 Hz)104.8 dB SPL
Max. short term SPL with IEC-weighted noise (IEC 60268-5) at 1 m, in typical listening conditions107 dB(C) SPL
Max. short term SPL with music material at 2.3 m in typical listening conditions (pair / full range)97 dB(C) SPL
Max. short term SPL with music material at 2.3 m, in typical listening conditions (pair with subwoofer)104 dB(C) SPL
Max. long term SPL with pink noise at 2.3 m, in typical listening conditions (single / pair full range)88 / 93 dB(C) SPL
Max. long term SPL with pink noise at 2.3 m, in typical listening conditions (single / pair with subwoofer)89 / 94 dB(C) SPL
Analog input(s)XLR: analog electronically balanced
Analog input impedance10k Ohms in position 94/108 dB SPL at 1 m; 20k Ohms in position 100/114 dB SPL at 1 m
Max. input level+24 dBu
Common mode rejection ratio (CMRR)>56 dB @ 15kHz
Input gain control (sensitivity)0 dB ... -15 dB
Output level control (output level in 1 m based on 0 dBu input level)94; 100; 108; 114 dB SPL
Controller designAnalog; active
Crossover frequency2.0 kHz
Crossover slope24 dB/oct; 4th order
Equalization: Bass0; -2.5; -5; -7.5 dB
Equalization: Low-Mid0; -1,5; -3; -4,5 dB
Equalization: Treble+1; 0; -1; -2 dB
Protection circuitryIndependent thermo limiters for woofer, tweeter. Woofer soft clip and excursion limiters. Amplifier overheat.
Infrasonic filter: frequency; slope30 Hz; 6 dB/oct.
Display: On; Normal OperationNeumann logo “White”
Display: Limit / Clip / Errors / Protection /Boot Mute / Shut Down MuteNeumann logo “Red”
Display BrightnessWhite:on/dimmed/off; Red:on/dimmed
Output power woofer amplifier (THD+N with limiter deactivated: 10%)80 W
Output power tweeter amplifier (THD+N with limiter deactivated: 10%)80 W
Output power woofer amplifier (THD+N with limiter deactivated: 0.1%)50 W
Output power tweeter amplifier (THD+N with limiter deactivated: 0.1%)50 W
Mains Power Supply: input voltage; frequency100-240V; 50/60 Hz
Power consumption (230 V / 100 V): Idle20 W
Power consumption (230 V / 100 V): Full output200 W
In-rush current (Peak)20 A
Cabinet materialAluminium
Cabinet surface finish; color (front / back)Powder-coated, White (RAL 9016)
Operating conditions+10° C to +40° C (+50° F to +104° F); <75% RH; non-condensing
Transport/storage conditions-25° C to +70° C (-13° F to 158° F); <90% RH, non-condensing
Woofer130 mm (5.25") magnetically shielded with protecting black metal grille
Tweeter25 mm (1") with protecting black metal grille
Mounting points2 x M8 threaded inserts with 70 mm spacing on back panel; thread depth 15 mm (5/8”)
Product dimensions (height x width x depth)277 x 182 x 220 mm (10 7/8” x 7 1/8” x 8 5/8”)
External net volume9.7 liters
Product weight6.4 kg (14 lbs 2 oz)
Packed dimensions (height x width x depth), mm (inches)415 x 365 x 280 mm (16 3/8” x 14 3/8” x 11”)
Packed weight8.4 kg (18 lbs 8 oz)
Packed cube0.042 m³
RenkSiyah
Hoparlör TürüStüdyo Monitör Hoparlörler
Hoparlör Ölçüsü5"
