| Output power (Peak) | 2400 W |
| Output power (RMS) | 800 W |
| Audio Inputs | |
| Input 1 / 2 | 2 x XLR, servo-balanced |
| Sensitivity | +4 dBu @ 0 dB (center position) for full rated power |
| Input impedance | 10 kΩ unbalanced, 20 kΩ balanced |
| Audio Outputs |
| Output 1 / 2 | 2 x XLR, servo-balanced |
| Output impedance | 1 kΩ unbalanced, 2 kΩ balanced |
| High-pass filter | 90 / 120 Hz, Butterworth, 24 dB/oct. slope |
| Controls |
| Level | -∞ to +6 dB, adjustable |
| Xover | 90 / 120 Hz, switchable |
| Outputs mode | Link / xover, switchable |
| Phase | 0 / 180°, switchable |
| System Data |
| Frequency range | 30 Hz to150 Hz (±3 dB) |
| Crossover frequency | 90 / 120 Hz, switchable |
| Signal-to-noise (100Hz) | > 90 dB |
| Sound pressure level (half space) | Max. 129 dB @ 1 m |
| Woofer | 18" (460 mm) |
| Limiter | Yes |
| Indicators |
| Signal LED | Green |
| Limit LED | Red |
| Power LED | Blue |
| Circuit Protection | |
| Amplifier protection | Full short circuit, open circuit, thermal protection |
| Power Supply, Voltage (Fuses) | |
| USA / Canada | 100-120 V~, 50/60 Hz (T 10 A L 250 V) |
| UK / Australia / Europe | 220-240 V~, 50/60 Hz (T 5 A L 250 V) |
| Korea / China | 220-240 V~, 50/60 Hz (T 5 A L 250 V) |
| Japan | 100-120 V~, 50/60 Hz (T 10 A L 250 V) |
| Power consumption | 210 W |
| Mains connection | Standard IEC receptacle |
| Dimensions / Weight | |
| Dimensions (H x W x D) | 650 x 530 x 609 mm (25.6 x 20.9 x 24.0") |
| Weight | 41.0 kg (90.2 lbs) |
