TEKNİK ÖZELLİKLER
Speaker Type
2-Way Active Speaker
Frequency Response [-10dB]
58 - 20.000 Hz
Frequency Response [- 3dB]
70 - 19.600 Hz
Max SPL
128 dB
HF
1" Exit, 1.4 v.c.
Type HF
Compression driver
Horizontal Directivity
100° (85° up/120° down)
Vertical Directivity
85° (+ 25°/-60°)
Horn
Asymmetrical Horn
LF
10", 2" v.c.
Amp Technology
Amp SMPS Power supply dual range
Amp Class
Class D
RMS Power
600 W
Peak Power
1200 W
Controller
DSP 56 bit
AD/DA Converter
24 bit/48 KHz
System Presets
Rotary Encoder (8 Presets)
CrossOver Frequency
2000 Hz
Limiter
Peak, RMS, Thermal
Advanced DSP Functions
Linear Phase FIR Filters
Signal Input
1xCombo (XLR/Jack 6.3 mm) MIC/Line
Signal Output
1xCombo (XLR/Jack 6.3 mm) MIC/Inst
1x XLR Male (CH1 Link/Mix OUT)
Selectable
Width
300 mm (11.81 in)
Height
552 mm (21.73 in)
Depth
301 mm (11.85 in)
Weight
12.3 kg (27.12 lbs)
Listedeki Ürün Resimleri, Donanım ve Teknik bilgiler zaman içinde farklılık gösterebilir. Üretici Ürün Özelliklerini değiştirme hakkını saklı tutar.
